ASUS Pro WS WRX80E-SAGE SE WIFI AMD WRX80 Socket SP3 Extended ATX

Ultimate performance for maximum productivity
The ASUS Pro WS WRX80E-SAGE SE WIFI is engineered to unleash the incredible power of the latest AMD® Ryzen® Threadripper™ Pro processors, providing a robust foundation for professional creative work that benefits from multi-core CPUs, such as video editing and 3D rendering. Additionally, seven PCIe 4.0 slots with SafeSlot reinforcement deliver exceptional performance with the latest high-end graphics cards.

Professional engineering in a low-profile size
With black metallic aluminum profiles, black stainless steel mesh fabric with highlighted details, and a smoky-gray transparent I/O cover, the Pro WS RX80E-SAGE SE WIFI offers a professional, understated look for content creators.

Multi-GPU Support
The Pro WS WRX80E-SAGE SE WIFI features seven PCIe® 4.0 x16 slots for high-end graphics cards, providing enhanced performance in professional design, modeling, simulation, and rendering applications.

Intel® Dual 10G Ethernet
The Pro WS WRX80E-SAGE SE WIFI features two integrated 10G LAN ports, powered by the cutting-edge Intel® X550-AT2 Ethernet controller. This not only enables lightning-fast multi-terabyte data transfers but also provides server-grade connections with low latency.

USB 3.2 Gen 2 x 2 Type-C
The latest USB standard doubles the transfer bandwidth by using an additional USB 3.2 Gen 2 lane to achieve a maximum throughput of up to 20Gbps. In addition to stunningly fast data transfer rates, USB 3.2 also offers easy connectivity and ultimate flexibility via its USB-C interfaces.

Front Panel Connector
The front-panel USB 3.2 Gen2 connector is ready for next-generation PC cases and devices.

3 M.2 PCIe 4.0
The Pro WS WRX80E-SAGE SE WIFI is equipped with three M.2 and two U.2 slots, featuring PCIe 4.0 x4 bandwidth. Content creators working with massive video files can combine multiple NVMe devices in a RAID array for enormous I/O bandwidth and seamless playback in their editing environments. These three slots are located under dedicated heatsinks to prevent SSD throttling under heavy load.

More Storage
With NVMe RAID support for Ryzen™ Threadripper™ PRO processors, unused CPU PCIe® 4.0 lanes can be assigned to storage. This allows you to set up a bootable RAID array with multiple M.2 SSDs, offering incredible throughput – up to 8x faster than single PCIe® 3.0 x4 SSDs. A RAID can also be configured with PCIe® 3.0 SSDs.

ECC Memory Support
AMD Ryzen™ Threadripper™ PRO processors offer unparalleled memory bandwidth and support 8 memory channels, up to 2048GB. By supporting ECC memory, data errors are automatically detected and corrected, reducing the likelihood of system crashes. The result is high stability for consistent, creative work.

Intel® Wi-Fi 6
The Intel® WiFi 6 AX200 module is compatible with the 802.11ax standard and increases the theoretical maximum bandwidth to an incredible 2.4Gbps. What may be even more important for power users is the optimization for more efficient operation in crowded networks with a lot of competing traffic. Combine your motherboard with an ASUS WiFi 6 router to fully exploit the network potential of WiFi 6.

SERVER-GRADE REMOTE MANAGEMENT
ASMB9-iKVM for Remote Management
An integrated BMC (Baseboard Management Controller) is an essential feature for workstations. It uses an Intel X55 dual 10-Gigabit Ethernet controller, with one port reserved for the BMC to provide the intelligence for the IPMI architecture. The BMC manages the interface between system management software and platform hardware. Administrators can communicate remotely with the BMC to take corrective actions – such as resetting or shutting down a system.

COMPREHENSIVE COOLING DESIGN
16 Power Stages
The VRM of the Pro WS WRX80E-SAGE SE WIFI consists of 16 power stages, which deliver more than enough power and efficiency for the latest AMD processors.

6-pin Power Connectors
Two additional 6-pin PCIe power connectors can improve power supply stability when a content creator uses multiple graphics cards.

SOC and DRAM Coolers
As mass and airflow are extremely important, our heatsinks are crafted with sharpened cooling fins, characterized by a particularly high aspect ratio. An SOC cooler uses a semi-passive fan to dissipate heat from the dual 10G LAN.

Active Cooler
The fin density has been optimized to maximize surface area while keeping resistance to air dissipation low. The special, quiet fan features an extremely durable bearing with a 60,000-hour L10 lifespan.

M.2 Cooler
Three M.2 slots are covered by heatsinks to prevent temperature-related throttling. This can impair performance under high, sustained storage utilization.

PERFECT FOR DIY SYSTEMS
Side-mounted connectors
Unique, side-mounted connectors on the front of the case keep cables away from graphics cards, ensuring clean cable routing, easier management, and an optimized installation process.
Pre-mounted I/O Shield
The patented I/O shield comes in elegant matte black and is pre-mounted on the motherboard for easy installation. It is designed to allow airflow that dissipates heat from the board.

BIOS Flashback™
The (UEFI) BIOS can be updated by copying a BIOS file to a FAT32-formatted USB stick, plugging it into the USB BIOS FlashBack™ port, and pressing a button. Updates can even be performed when no RAM and no CPU are installed.

WORK WITH FUN
Immersive Audio Experience
The Realtek ALC4080 audio codec features a high-quality 120dB SNR stereo playback output and a 113dB SNR recording input for pristine audio quality. It is supported by EMI shielding and separate PCB layers for the left and right channels to ensure optimal signal integrity. Additionally, DTS:X Ultra technology enables louder, immersive 3D surround sound.

Power Pre-regulator
Reduces power supply interference to ensure consistent performance.

Separate Layers for Left and Right Channels
Guarantees minimal crosstalk between audio paths.
Audio Shielding
Separates analog/digital domains and drastically reduces multilateral interference.
De-Pop Circuit
Reduces popping noise when plugging and unplugging at all audio outputs.
Integrated Amplifier
Allows driving high-impedance headphones without level drops at high or low frequencies.
Premium Japanese Capacitors
Premium components offer an immersive sound signature with exceptional fidelity.
RELIABLE STABILITY
FOR HIGH RELIABILITY
Rigorously Tested Compatibility
The Pro WS WRX80E-SAGE SE WIFI has been extensively tested and validated for compatibility and reliability across various environments and applications.

520+
DDR4 Compatibility
Industry-leading DDR4 memory compatibility for optimal flexibility and worry-free operation.

1000+
Compatible Devices
Compatible with a range of CPUs, memory modules, graphics cards, and more.

8000+
Testing Hours
Extensive testing with the latest components for enhanced reliability, compatibility, and safety.

Protect Your Graphics Card
SafeSlot is a PCIe® slot newly developed by ASUS to guarantee optimized fastening and high protection against shear forces. SafeSlot is manufactured in a single step using a new insert-molding process and stabilizes the slot with metal for improved stability and durability.

24/7 Reliability
Optimized for 24/7 operation, the Pro WS WRX80E-SAGE SE WIFI is tested under temperatures of up to 45°C and humidity of up to 80% to ensure flawless operation in various environments.
